Description
Product Features
lightweight and easy to carry. It is foldable, with flip-up armrests, adjustable and detachable footrests. The joystick controller is interchangeable for left/right-hand use. It is equipped with a Taiwan-made worm gear motor and an automatic electromagnetic brake system.
Wheelchair Technical Specifications
| Parameter | Specification |
|---|---|
| Range per charge | 15 – 20 km |
| Max. speed | 6 km/h |
| Battery | 24V 20Ah |
| Motor | 250W × 2 pcs |
| Controller | Intelligent joystick controller |
| Brake system | Automatic electromagnetic brake |
| Frame colors | Flame Blue, Shiny Silver |
| Seat cushion color | Mesh Blue |
Wheelchair Dimensions & Weights
| Parameter | Specification |
|---|---|
| Net weight | 43 kg |
| Overall length | 1060 mm |
| Overall width | 610 mm |
| Overall height | 940 mm |
| Seat width | 450 mm |
| Seat depth | 430 mm |
| Backrest height | 395 mm |
| Seat height (from ground) | 490 mm |
| Folded width | 320 mm |
| Front wheel size | 8 inch |
| Rear wheel size | 12 inch |
| Max. user weight | 100 kg |
